Male Circulatory System 3D Model

Solid 3D Male Circulatory System

Solid 3D Male Circulatory System

Need to model a system involving the Blood Flow or the Heart?

Zygote's detailed Solid 3D Male Circulatory System is perfect for:

  • Catheter or Stent Engineering
  • Cardiac Fluid Dynamics Studies
  • Simulating Cardiac Interventions & Treatments
  • CAD Product & Device Design

Developed from medical scans, these high fidelity 3D geometries of the Circulatory System can be depended on for accurate results.

Includes the Zygote Solid 3D Heart Model.

A free eDrawing of this model is available. What is an eDrawing? Click here to find out more.

Zygote's Solid 3D Anatomy has set the standard in CAD and Simulation for over a decade.

  • Formats:
    • ProE/Creo
    • IGES
    • ParaSolid
    • SolidWorks
    • Step
  • Delivery Method: Download
  • Price: $4,800
Schedule a Demo

"3D Science's [Zygote's] services and models have proven themselves time and time again. When the producers for television show "The Doctors" approached me to develop a graphics solution to their daily dose of medical information, I immediately knew that they needed the Zygote Human Anatomy Collection. The collection has been a critical piece of the toolkit ever since. I've been using their models and services since 2004 and have not found anything that comes close. The accuracy and high level of detail saved us hundreds of hours in potential clean-up and preparation. Above all, the efficient mesh density makes their models easy to work with, manipulate and render on a tight budget and deadline."

Brian Johnson / President - Longerday Productions, Inc.

The Solid 3D Male Circulatory System includes the heart and pericardium as well as blood vessels serving the heart, head, trunk, pelvis, arms and legs. Blood vessel interior diameters were acquired through use of scans leveraging contrasting agent. Diameters, contours and wall thickness of the blood vessels of the heart, neck, vena cava, aorta and proximal femoral arteries conform to data obtained from medical scans. Vessel wall thickness throughout the rest of the body was developed by projecting the same ratio of interior vessel diameter to blood vessel wall thickness as observed in scans, down through the extremities.

The heart is a component of a larger anatomy collection that includes anatomical geometries taken from different scan subjects and integrated into a whole-body assembly of a 50th percentile (U.S. by height and weight) Caucasian male. Full-body scan data of this individual provided the over-all template or infrastructure for the entire assembly of the circulatory system constructed from various scan inputs - including contrast-dye scans of different scan subjects. The Heart was developed from an excellent heart scan of a subject different than the primary template subject. The resultant heart data was subsequently positioned, without changing the proportions or shape, to fit the 50th percentile male scan data.
